100N Series Piston Diaphragm Sludge Discharge Valve

Product Overview

             Size Range: DN100–DN500

             Pressure Rating: PN0.6–2.5 MPa

             Temperature Range: 0–80°C

             Applicable Media: Water, sewage, and similar fluids

             Structure Type: Diaphragm, piston, Y-type

             Connection Type: Flanged

             Actuation Method: Pneumatic or hydraulic

             Body Materials: Cast iron, carbon steel, stainless steel, ductile iron

             Diaphragm Plate & Valve Disc Materials: Ductile iron, stainless steel, bronze

             Stem Material: Stainless steel

             Diaphragm Material: Nylon-reinforced rubber

Key Features

             Durable Diaphragm: The internal diaphragm is made of nylon-reinforced rubber, offering excellent wear and corrosion resistance, which extends the valve's service life.

             Fast Operation: The valve provides rapid opening and low closing pressure, ensuring efficient sludge discharge.

             Y-Type Structure: The Y-type design facilitates smooth flow, reducing blockage risks and enhancing discharge efficiency.

             Remote Control Capability: The valve can be operated via external pneumatic or hydraulic control lines, allowing for centralized and automated control.

Advantages

             Efficient Sludge Removal: Specifically designed for removing sediment and sludge from pools and tanks, maintaining system cleanliness.

             Extended Service Life: High-quality materials and robust construction contribute to a long operational lifespan.

             Versatile Application: Suitable for various water treatment and sewage systems, including sedimentation tanks and wastewater treatment plants.

             Ease of Maintenance: Simple structure allows for convenient installation and maintenance, reducing downtime.

100S/100V Series Angle Sludge Discharge Valve

Product Overview

             Applicable Sizes: DN100–DN500

Pressure Rating: PN0.6–2.5MPa

Operating Temperature: 0–80°C

Fluid Media: Water, sewage, etc.

Structure Types: Diaphragm type, piston type, Y-type

Connection Method: Flanged

Actuation Method: Pneumatic, hydraulic

Valve Body Materials: Cast iron, carbon steel, stainless steel, ductile iron

Diaphragm Plate and Disc Materials: Ductile iron, stainless steel, bronze

Stem Material: Stainless steel

Diaphragm Material: Nylon-reinforced rubber

Features and Advantages

Rapid Operation: Pneumatic or hydraulic actuation ensures quick response for efficient sludge discharge.

Reliable Structure: Diaphragm design separates the valve into two chambers, preventing direct contact between the medium and the actuator, extending service life.

Excellent Sealing: Nylon-reinforced rubber diaphragm combined with metal seat ensures tight sealing and prevents leakage.

Easy Installation and Maintenance: Angle structure design facilitates installation at the bottom or side wall of sedimentation tanks, with convenient maintenance.

Wide Applicability: Suitable for water plants, sewage treatment plants, and systems requiring regular sludge discharge.

JM742 Series Bottom Sludge Discharge Valve

Product Overview

Size Range: DN100–DN500

Pressure Rating: PN0.6–2.5 MPa

Temperature Range: 0–80°C

Applicable Media: Water, sewage, and similar fluids

Structure Type: Diaphragm, piston, Y-type

Connection Type: Flanged

Actuation Method: Pneumatic or hydraulic

Body Materials: Cast iron, carbon steel, stainless steel, ductile iron

Diaphragm Plate & Valve Disc Materials: Ductile iron, stainless steel, bronze

Stem Material: Stainless steel

Diaphragm Material: Nylon-reinforced rubber

Key Features

Dual-Chamber Diaphragm Actuation: Utilizes a dual-chamber diaphragm mechanism instead of a piston, eliminating mechanical wear and enhancing durability.

Rapid Operation: Designed for quick opening and closing, facilitating efficient sludge discharge.

Automated Control: Compatible with PLC programming for remote, automatic, or centralized control, allowing for real-time monitoring of valve status.

High Sealing Performance: Features a diaphragm that effectively isolates the actuator from the medium, ensuring reliable sealing and preventing leakage.

Advantages

Enhanced Durability: The diaphragm's design reduces wear and extends the valve's service life, making it suitable for handling abrasive media.

Efficient Sludge Removal: Ideal for sedimentation tanks and wastewater treatment facilities, ensuring effective removal of accumulated sludge.

Flexible Control Options: Supports various control methods, including manual, automatic, and remote operation, to meet diverse operational needs.

Maintenance-Friendly: Simplified design allows for easy maintenance and reduced downtime, minimizing operational disruptions.
